現有的涼茬設備大都位于地下，安裝的工程量大，時間長，使用時漏在地下風道的茬料無法回收，造成較嚴重的浪費。攪拌方式多采用震動式攪拌，攪拌不均勻，冷卻效果差，容易造成設備堵塞。另外現在的酒曲下料及茬料混合大多采用人工作業，勞動強度大，上料效率低，嚴重影響涼茬作業的工作效率。
Most of the existing cooling stubble equipment is located underground, and the installation quantity is large and the time is long. The stubble leaked in the underground air duct during use cannot be recycled, causing a serious waste. Most of the mixing methods are vibration mixing, which is uneven and has poor cooling effect, which is easy to cause equipment blockage. In addition, most of the current distiller's yeast cutting and stubble mixing are manual operations, which have high labor intensity and low feeding efficiency, seriously affecting the working efficiency of the cool stubble operation.
為上述問題，本實用新型的目的在于提供一種全
自動涼茬機，該設備無需安裝在地下，平整地面即可完成安裝。兩側設護板，防止在攪拌過程中茬料的掉落，加裝多根攪輥，攪拌茬料更加均勻。采用鏈板式輸送機，并且支架上安裝風機與風箱，對茬料進行吹風降溫作業，結構緊湊，自動化程度高，較少需要人工干涉。
To solve the above problems, the purpose of the utility model is to provide a full-automatic stubble cooling machine, which can be installed without being installed underground and leveling the ground. Guard plates are set on both sides to prevent the stubble from falling during mixing. Multiple mixing rollers are added to make the stubble more uniform. The chain plate conveyor is adopted, and the fan and bellows are installed on the support to blow and cool the stubble. The structure is compact, the degree of automation is high, and less manual interference is required.
本實用新型的積極效果在于：
The positive effects of the utility model are:
不用安裝在地下，安裝的工作量小。設有茬料斗和自動下曲斗，自動化程度高，降低人工勞動強度，減少人為干涉，保證茬料 一種全自動涼茬機，包括支架，在所述支架內側設有兩塊護板，兩塊護板之間設有鏈板式輸送機，在所述支架上方分別設有茬料斗和灑水器；在所述護板的出料端設有第二支架，第二支架上設有第二鏈板式輸送機和第三鏈板式輸送機，鏈板式輸送機的出料端位于第二鏈板式輸送機進料端上方，第二鏈板式輸送機的出料端位于第三鏈板式輸送機的進料端上方，第三鏈板式輸送機的出料端處設有出料口，第二支架上方并排設有兩塊第二護板，第二鏈板式輸送機和第三鏈板式輸送機位于兩塊第二護板之間，第二支架上設有自動下曲斗，自動下曲斗位于第三鏈板式輸送機上方；鏈板式輸送機、第二鏈板式輸送機和第三鏈板式輸送機的鏈板均為帶孔鏈板。
It does not need to be installed underground, and the installation workload is small. It is equipped with stubble hopper and automatic lower bending hopper, with high degree of automation, reducing manual labor intensity, reducing human interference, and ensuring stubble material. It is a fully automatic stubble cooler, including a first support. There are two first guard plates on the inside of the first support, and a first chain plate conveyor is set between the two first guard plates, and stubble hopper and sprinkler are respectively set above the first support; The discharge end of the first guard plate is provided with a second support, the second support is provided with a second chain plate conveyor and a third chain plate conveyor, the discharge end of the first chain plate conveyor is located above the feed end of the second chain plate conveyor, the discharge end of the second chain plate conveyor is located above the feed end of the third chain plate conveyor, and the discharge end of the third chain plate conveyor is provided with a discharge port, Two second guard plates are arranged side by side above the second support, the second chain plate conveyor and the third chain plate conveyor are located between the two second guard plates, the second support is equipped with an automatic lower hopper, and the automatic lower hopper is located above the third chain plate conveyor; The chain plates of the first chain plate conveyor, the second chain plate conveyor and the third chain plate conveyor are all chain plates with holes.
在所述第二護板上靠近支架的一側設有電機箱，在遠離支架的一側設有第三電機箱，在所述電機箱與第三電機箱之間還設有第二電機箱；所述電機箱，第二電機箱和第三電機箱分別對應控制安裝在第二護板上的攪輥，第二攪輥和第三攪輥，自動下曲斗位于第二電機箱和第三電機箱之間。在所述第二支架內側靠近護板的一側設有風箱，遠離護板的一側設有第二風箱，在所述風箱的前部設有風機，在第二風箱的前部設有第二風機；風箱和風機位于第二鏈板式輸送機內部；第二風箱和第二風機位于第三鏈板式輸送機內部。在第二支架上，位于第二鏈板式輸送機與第三鏈板式輸送機之間設有沖刷系統，沖刷系統由水平設置的總管和總管上的噴嘴構成。在所述茬料斗內的側壁上并排設有兩條橫向滑軌，兩條橫向滑軌上并排安裝有兩個移動攪拌單元；所述每個移動攪拌單元均包括兩個橫移小車，橫移小車內設有驅動裝置及配套的行走裝置，可使橫移小車沿橫向滑軌自由滑動，每個橫移小車上均設有軸承座，兩個軸承座之間安裝有第四攪輥，其中一個橫移小車的一側安裝有旋轉電機，旋轉電機與第四攪輥相連接，可帶動第四攪輥旋轉運動。免受污染。采用攪輥攪拌可以將茬料充分分散晾曬，加裝的護板在保證攪拌的同時，茬料不會掉落，減少了原料的浪費。
A first electric chassis is arranged on the side near the first bracket on the second guard board, a third electric chassis is arranged on the side far from the first bracket, and a second electric chassis is also arranged between the first electric chassis and the third electric chassis; The first electric case, the second electric case and the third electric case respectively control the first stirring roller, the second stirring roller and the third stirring roller installed on the second guard plate, and the automatic lower hopper is located between the second electric case and the third electric case. A first air box is arranged at the side close to the first guard board at the inner side of the second support, a second air box is arranged at the side far from the first guard board, a first fan is arranged at the front of the first air box, and a second fan is arranged at the front of the second air box; The first air box and the first fan are located inside the second chain plate conveyor; The second air box and the second fan are located inside the third chain plate conveyor. On the second support, there is a scouring system between the second chain plate conveyor and the third chain plate conveyor. The scouring system is composed of a horizontally arranged header and a nozzle on the header. Two transverse slide rails are arranged side by side on the side wall of the stubble hopper, and two mobile mixing units are arranged side by side on the two transverse slide rails; Each mobile mixing unit includes two transverse cars. The transverse car is equipped with a driving device and a supporting traveling device, which can make the transverse car slide freely along the transverse slide rail. Each transverse car is equipped with a bearing seat. A fourth mixing roller is installed between the two bearing seats. One side of the transverse car is equipped with a rotating motor. The rotating motor is connected with the fourth mixing roller, which can drive the fourth mixing roller to rotate. Free from pollution. The stubble can be fully dispersed and dried by using the mixing roller. The added guard plate ensures that the stubble will not fall while mixing, reducing the waste of raw materials.
風箱是頂部不設蓋板，且位于鏈板式輸送機內部，風機吹出的風只能向鏈板式輸送機的上層鏈板方向吹，實現在攪拌的同時對上導鏈板上的茬料吹風降溫，冷卻效果顯著提高。
The air box is not equipped with a cover plate at the top, and is located inside the chain plate conveyor. The air blown by the fan can only blow in the direction of the upper chain plate of the chain plate conveyor, so as to realize the cooling of the stubble on the upper chain plate while mixing, and the cooling effect is significantly improved.
In addition, a scouring system is added between the two chain plates to avoid poor ventilation caused by the blocking of the chain plate conveyor, and the washed stubble can be recycled, reducing the waste of resources. For more equipment related questions, please visit our website http://www.youjizz-sex.com Ask about it!
