自動涼茬機主要由機架、風機、傳送帶和順次銜接于傳送帶上的攪籠、打料棍、翻料棍、下料設備、出料管組成，下面來講講自動涼茬機電機運用前的檢查技術。
The automatic stubble cooler is mainly composed of a frame, a fan, a conveyor belt, and a stirring cage, a beating rod, a tipping rod, a blanking device, and a discharge pipe connected to the conveyor belt in sequence. Next, we will talk about the inspection technology before the automatic stubble cooler motor is used.
自動涼茬機是能酒茬攤涼拌和后，加入酒曲混合的一種設備。作業時間短、十分節省資源、主動加曲卸料、減輕了工人們的勞動強度，還杜絕了糟蹋糧食的現象。與糧食觸摸的部分均為優良的不銹鋼材料。此外，自動涼茬機在運用時輸送、拌和、下曲是都可以變頻調速的。
Automatic stubble cooler is a kind of equipment that can add liquor koji to mix after cold mixing of wine stubble. The operation time is short, the resources are saved, the material is added and unloaded actively, the labor intensity of workers is reduced, and the phenomenon of spoiling grain is also put an end to. The parts touching the grain are made of excellent stainless steel. In addition, when the automatic stubble cooler is used, the conveying, mixing and bending can all be regulated by frequency conversion.
1、用壓縮空氣或手動吹風機吹凈電動機內部灰塵、電刷粉末等，鏟除塵垢雜物。
1. Use compressed air or manual blower to blow the dust and brush powder inside the motor and remove the dirt and sundries.
2、撤除與電動機銜接的全部接線，用絕緣電阻表丈量繞組對機座的絕緣電阻。若小于0.5MΩ時，應進行烘干處理，丈量合格后再將撤除的接線康復。
2. Remove all wiring connected with the motor and measure the insulation resistance of the winding to the base with an insulation resistance meter. If it is less than 0.5M Ω, it shall be dried, and the removed wiring shall be recovered after the measurement is qualified.
3、查看
自動涼茬機換向器的表面是否光亮，如果發現有機械損害或火花灼痕要進行必要的處理。
3. Check whether the surface of the commutator of the automatic stubble cooler is bright. If any mechanical damage or spark marks are found, carry out necessary treatment.
4、查看電刷是否嚴峻損壞，刷架的壓力是否恰當，刷架的方位是否坐落符號的方位。
4. Check whether the brush is severely damaged, whether the pressure of the brush holder is appropriate, and whether the position of the brush holder is located in the position of the symbol.
5、依據自動涼茬機電動機銘牌查看直流電動機各繞組之間的接線方法是不是正確，電動機額定電壓與電源電壓是否相符，電動機起動設備是否符合質量要求，是不是完好無缺。
5. Check whether the wiring method between the windings of the DC motor is correct, whether the rated voltage of the motor is consistent with the power supply voltage, whether the starting equipment of the motor meets the quality requirements and whether it is intact according to the motor nameplate of the automatic stubble cooler.
